Victron energy BatteryProtect 12/24V-100A

Description

🔋 Victron BatteryProtect BP-100 – 12/24V 100A (BPR000100400)

Protect your battery investment with the Victron BatteryProtect BP-100 (BPR000100400). Designed to automatically disconnect loads before your battery is critically discharged, this intelligent 12V/24V battery protection device ensures maximum lifespan and performance for lithium, AGM, or lead-acid batteries. With a 100A continuous current capacity and programmable voltage thresholds, it’s the perfect solution for off-grid solar systems, RV power setups, marine battery banks, and backup energy storage.

Featuring automatic voltage detection, ultra-low power consumption, and solid-state MOSFET switching, the Victron BP-100 delivers reliable protection with zero sparks and minimal energy draw. It also supports LiFePO4 battery banks through integration with battery management systems (BMS).

✅ Key Features

• Automatic 12V / 24V system detection

• 100A continuous current with 600A peak (30s)

• Programmable disconnect/reconnect voltage levels

• LiFePO4 BMS support (Li-ion mode)

• Spark-free solid-state switching

• Ultra-low quiescent current (<1.5 mA)

• 12s alarm delay and smart reconnect logic

• Compact and easy to install in tight spaces

📦 Applications

• Off-grid and hybrid solar power systems

• Recreational vehicles (RVs) and campervans

• Marine electrical systems and boats

• Telecom and backup battery systems

• Energy storage with lithium or AGM batteries

📐 Specifications

• Model: BPR000100400

• Voltage Range: 6–35V DC

• Continuous Current: 100A

• Peak Current: 600A (30s)

• Dimensions: 59 x 42 x 115 mm

• Weight: 0.2 kg

Boost battery life and prevent deep discharge damage with the Victron BP-100. Ideal for reliable and safe battery operation in demanding power systems.
